シマノ スモールパーツ・補修部品 BRM355ブリードボスキャップ Y88F06000《S》 SHIMANO - ショッピング・ショップ | 通販検索

シマノ スポーツバイク ロードバイク クロスバイク

Disc Brake

BR-RS785 Brake Caliper

番号

型番

商品名

01

Y8AL98020

Connecting Bolt Unit

02

Y8H298040

Olive & Connecter Insert

03

Y8H802000

Hose Cover for easy hose joint system, not used with easy hose joint direct system

04

Y8H198030

TL-BH61 Shimano original tool (2 pcs.)

05

Y83098040

SM-HANG Hose Supporter A & B

06

Y88F06000

Bleed Boss Cap

07

Y8LS98030

Bleed Screw & Nipple Seal

Y8LS98010

Bleed Screw & Nipple Seal (Discontinued)

08

Y8VZ07000

Bleed Screw

Y8LS06000

Bleed Screw (Discontinued)

09

Y8B511001

Bleed Nipple Seal

10

Y8LS98020

Caliper Fixing Bolt (M6 x 18.7) & Snap Ring

11

Y8C511000

Snap Ring

12

Y8LS05000

Caliper Fixing Bolt (M6 x 18.7)

13

Y8B298010

Wire (2 pcs.)

14

Y8J721000

Caliper Fixing Bolt (M6 x 15.2)

15

Y8J798060

Pad Axle & Snap Retainer

16

Y8J710000

Pad Axle

17

Y8J716000

Snap Retainer

18

Y8LW98020

Resin Pad G02A Spring w/Split Pin

19

Y8JZ98020

Metal Pad (G03S) & Spring w/Split Pin

20

Y8LW98040

Resin Pad (J02A) w/Fin & Spring w/Split Pin

21

Y8LW98030

Metal Pad (J04C) w/Fin & Spring w/Split Pin

22

Y8DB06100

Split Pin

23

Y8J709000

Pad Spacer

24

Y8J712000

Bleeding Spacer

25

Y8K198010

Lock Ring & Washer

26

Y12009230

TL-LR15 Lock Ring Removal Tool

27

Y83998010

Mineral Oil Bleed Kit (50 ml)

28

Y81741100

Converter Fixing Bolt (M5 x 14)

29

Y81798020

Caliper Fixing Nut & Washer

30

Y81743100

Converter Fixing Bolt (M5 x 16.8) for 10 mm Rear mount thickness

Y81743150

Converter Fixing Bolt (M5 x 21.8) for 15 mm Rear mount thickness

Y81743200

Converter Fixing Bolt (M5 x 26.8) for 20 mm Rear mount thickness

Y81743250

Converter Fixing Bolt (M5 x 31.8) for 25 mm Rear mount thickness

Y81743300

Converter Fixing Bolt (M5 x 36.8) for 30 mm Rear mount thickness

Y81743350

Converter Fixing Bolt (M5 x 41.8) for 35 mm Rear mount thickness

31

Y26L98030

Lock Ring & Washer (Externally serrated type)

32

Y13098000

TL-FC36 Lock Ring Removal Tool
